AC Input: 88-264 VAC, 47-63 Hz
Galvanic Isolation (input-output): 3 kVAC
+24 Volt Output: Simultaneously drives the FX-2100 DC-to-DC power converter and 12 volt battery charger
Compatible Battery Voltage/Chemistry: 12 V AGM, gel, sealed lead acid (SLA) or 12 V lithium iron phosphate (LiFePO4) drop-in lead acid replacement types
12 Volt Battery Charger: Three-stage battery charger
Constant current (CC)/constant voltage (CV) (<13.2 V): 0.75 A ±10%/14.4 V
Float Charge (< 0.1A): 13.5 V
Battery Disconnect/Reconnect Voltage: 11.8 V disconnect/12.6 V connect
Depleted (<10 V): Trickle charge 0.15 A
Charge Temperature: 0˚C to +40˚C; temperature protection on/off control
EOC: User selectable end of charge (EOC) time
Charger Status LEDs: Charge and fault binary operation reports standby (not charging), battery fault, normal charging & temperature fault
AC Connector: IEC 320-C14 with V-Lock secure retention system (Mating IEC320-13 to NEMA 5-15P, V-Lock, 2-meter, AC power cable supplied)
Battery Mating Connector: Two circuit Phoenix Contact mating connector 1847055 supplied
